Werkende voorbeelden
Hieronder staan complete flowdefinities die aansluiten op het huidige
schema met id, sourceId, targetId en correcte branches.
Doel: vergelijk de laatste 7 dagen met de 7 dagen daarvoor.
Als omzet daalt, stuur warn; anders info.
{
"id": "auto_weekly_revenue_compare",
"name": "Weekly Revenue Compare",
"description": "Waarschuwing wanneer omzet lager is dan vorige week",
"nodes": [
{
"id": "trigger_weekly",
"type": "trigger",
"title": "Wekelijks maandag 08:00",
"position": { "x": 120, "y": 120 },
"trigger": { "schedule": "0 8 * * 1" }
},
{
"id": "ds_testdata",
"type": "datasource",
"title": "Facturen",
"position": { "x": 420, "y": 120 },
"data": { "dataSourceId": "testdata" }
},
{
"id": "flt_current",
"type": "filter",
"title": "Huidige 7 dagen",
"position": { "x": 720, "y": 40 },
"filter": {
"rules": [
{ "field": "status", "type": "text", "values": ["paid"], "enabled": true },
{ "field": "invoice_date", "type": "date", "datePreset": "past7", "enabled": true }
]
}
},
{
"id": "flt_previous",
"type": "filter",
"title": "Vorige 7 dagen",
"position": { "x": 720, "y": 210 },
"filter": {
"rules": [
{ "field": "status", "type": "text", "values": ["paid"], "enabled": true },
{ "field": "invoice_date", "type": "date", "datePreset": "past7_shift1w", "enabled": true }
]
}
},
{
"id": "metric_revenue_current",
"type": "metric",
"title": "Omzet huidig",
"position": { "x": 1040, "y": 40 },
"metric": {
"key": "revenue_current",
"label": "Omzet huidig",
"aggregation": "sum",
"measureField": "line_total"
}
},
{
"id": "metric_revenue_previous",
"type": "metric",
"title": "Omzet vorige",
"position": { "x": 1040, "y": 210 },
"metric": {
"key": "revenue_previous",
"label": "Omzet vorige",
"aggregation": "sum",
"measureField": "line_total"
}
},
{
"id": "cond_revenue_down",
"type": "condition",
"title": "Omzet lager?",
"position": { "x": 1320, "y": 120 },
"condition": {
"operator": "<",
"left": { "source": "metric", "nodeId": "metric_revenue_current", "key": "revenue_current" },
"right": { "source": "metric", "nodeId": "metric_revenue_previous", "key": "revenue_previous" }
}
},
{
"id": "action_warn",
"type": "action",
"title": "Omzet daalt",
"description": "Omzet daalt: huidig={{revenue_currentValue}}, vorige={{revenue_previousValue}}",
"position": { "x": 1600, "y": 50 },
"action": { "channel": "Notification", "target": "all", "severity": "warn" }
},
{
"id": "action_ok",
"type": "action",
"title": "Omzet stabiel",
"description": "Omzet is stabiel of hoger. huidig={{revenue_currentValue}}",
"position": { "x": 1600, "y": 220 },
"action": { "channel": "Notification", "target": "all", "severity": "info" }
}
],
"connections": [
{ "id": "e1", "sourceId": "trigger_weekly", "targetId": "ds_testdata", "branch": "default" },
{ "id": "e2", "sourceId": "ds_testdata", "targetId": "flt_current", "branch": "default" },
{ "id": "e3", "sourceId": "ds_testdata", "targetId": "flt_previous", "branch": "default" },
{ "id": "e4", "sourceId": "flt_current", "targetId": "metric_revenue_current", "branch": "default" },
{ "id": "e5", "sourceId": "flt_previous", "targetId": "metric_revenue_previous", "branch": "default" },
{ "id": "e6", "sourceId": "metric_revenue_current", "targetId": "cond_revenue_down", "branch": "default" },
{ "id": "e7", "sourceId": "metric_revenue_previous", "targetId": "cond_revenue_down", "branch": "default" },
{ "id": "e8", "sourceId": "cond_revenue_down", "targetId": "action_warn", "branch": "if" },
{ "id": "e9", "sourceId": "cond_revenue_down", "targetId": "action_ok", "branch": "else" }
]
}Doel: AI beslist true/false of een metric een outlier is. True stuurt critical notificatie, false stuurt informatieve melding.
{
"id": "auto_ai_outlier_guard",
"name": "AI Outlier Guard",
"nodes": [
{
"id": "trigger_daily",
"type": "trigger",
"title": "Dagelijks 07:00",
"position": { "x": 120, "y": 120 },
"trigger": { "schedule": "0 7 * * *" }
},
{
"id": "ds_testdata",
"type": "datasource",
"title": "Factuurbron",
"position": { "x": 380, "y": 120 },
"data": { "dataSourceId": "testdata" }
},
{
"id": "flt_last_30d",
"type": "filter",
"title": "Laatste 30 dagen",
"position": { "x": 650, "y": 120 },
"filter": {
"rules": [
{ "field": "invoice_date", "type": "date", "datePreset": "past30", "enabled": true }
]
}
},
{
"id": "metric_invoice_count",
"type": "metric",
"title": "Aantal facturen",
"position": { "x": 920, "y": 120 },
"metric": {
"key": "invoice_count",
"label": "Aantal facturen",
"aggregation": "count",
"measureField": "invoice_id"
}
},
{
"id": "llm_outlier_gate",
"type": "llmcondition",
"title": "Outlier check",
"position": { "x": 1200, "y": 120 },
"llm": {
"systemPrompt": "Je bent een data quality agent. Antwoord alleen true of false.",
"userTemplate": "Metric aantal facturen={{invoice_countValue}}. Is dit een significante outlier t.o.v. recente trend?",
"responseKey": "outlierDecision",
"temperature": 0.1,
"maxTokens": 100,
"includeHistory": true
}
},
{
"id": "action_critical",
"type": "action",
"title": "Outlier gedetecteerd",
"description": "Outlier alert. Aantal facturen={{invoice_countValue}}",
"position": { "x": 1480, "y": 40 },
"action": { "channel": "Notification", "target": "all", "severity": "critical" }
},
{
"id": "action_normal",
"type": "action",
"title": "Geen outlier",
"description": "Geen outlier volgens AI. route={{outlierDecisionRoute}}",
"position": { "x": 1480, "y": 210 },
"action": { "channel": "Notification", "target": "all", "severity": "info" }
}
],
"connections": [
{ "id": "a1", "sourceId": "trigger_daily", "targetId": "ds_testdata", "branch": "default" },
{ "id": "a2", "sourceId": "ds_testdata", "targetId": "flt_last_30d", "branch": "default" },
{ "id": "a3", "sourceId": "flt_last_30d", "targetId": "metric_invoice_count", "branch": "default" },
{ "id": "a4", "sourceId": "metric_invoice_count", "targetId": "llm_outlier_gate", "branch": "default" },
{ "id": "a5", "sourceId": "llm_outlier_gate", "targetId": "action_critical", "branch": "if" },
{ "id": "a6", "sourceId": "llm_outlier_gate", "targetId": "action_normal", "branch": "else" }
]
}Doel: voer eerst een Element uit voor transformatie, en daarna een Element action voor rapport/verzending.
{
"id": "auto_element_pipeline",
"name": "Element Enrichment Pipeline",
"nodes": [
{
"id": "trigger_daily",
"type": "trigger",
"title": "Dagelijks",
"position": { "x": 120, "y": 120 },
"trigger": { "schedule": "0 9 * * *" }
},
{
"id": "ds_orders",
"type": "datasource",
"title": "Orders",
"position": { "x": 380, "y": 120 },
"data": { "dataSourceId": "testdata" }
},
{
"id": "elem_enrich",
"type": "elementnode",
"title": "Enrichment",
"position": { "x": 660, "y": 120 },
"element": {
"elementId": "orders_enrichment",
"entrypoint": "run",
"timeoutSeconds": 120,
"responseKey": "enrichedRows",
"params": {
"source": "{{dataSourceId}}",
"limit": 500
}
}
},
{
"id": "elem_send_report",
"type": "elementaction",
"title": "Rapport versturen",
"position": { "x": 980, "y": 120 },
"element": {
"elementId": "send_management_report",
"entrypoint": "run",
"timeoutSeconds": 90,
"responseKey": "reportDispatch",
"params": {
"rows": "{{enrichedRowsRows}}",
"target": "management"
}
}
},
{
"id": "action_done",
"type": "action",
"title": "Pipeline klaar",
"description": "Element pipeline klaar. records={{enrichedRowsRows}}",
"position": { "x": 1290, "y": 120 },
"action": { "channel": "Notification", "target": "all", "severity": "info" }
}
],
"connections": [
{ "id": "p1", "sourceId": "trigger_daily", "targetId": "ds_orders", "branch": "default" },
{ "id": "p2", "sourceId": "ds_orders", "targetId": "elem_enrich", "branch": "default" },
{ "id": "p3", "sourceId": "elem_enrich", "targetId": "elem_send_report", "branch": "default" },
{ "id": "p4", "sourceId": "elem_send_report", "targetId": "action_done", "branch": "default" }
]
}Maak een Autoflow met:
- trigger daily 08:00
- datasource testdata
- 2 filters: past7 en past7_shift1w
- 2 metrics: sum(line_total)
- condition: current < previous
- actions: warn if, info else
Gebruik:
- node id op elke node
- connections met sourceId en targetId
- branch if/else op condition edgesBouw flow met:
- trigger dagelijks
- datasource + metric count
- llmcondition die true/false antwoordt
- if: critical notification
- else: info notification
Belangrijk:
- llm.userTemplate verplicht invullen
- llmcondition moet twee outgoing branches hebben: if en else
- geen extra onbekende node types of velden
